Semi-hermetic reciprocating compressors from BITZER are universal. They boast high refrigerating capacities and optimal efficiency even in part load, with minimal energy requirements. Optimised versions are available for natural refrigerants. The IQ MODULE provides intelligent control and capacity control.
| Dimensions: Width x Height x Depth | 259 mm x 307 mm x 403 mm |
|---|---|
| Displacement (1450 RPM 50Hz) | 13.42 m³/h |
| Displacement (1750 RPM 60Hz) | 16.20 m³/h |
| No. of cylinder x bore x stroke | 2 x 50 mm x 39.3 mm |
| Weight | 73 kg |
| Max. pressure (LP/HP) | 19 / 32 bar |
| Connection suction line | 22 mm - 7/8'' |
| Connection discharge line | 16 mm – 5/8'' |
| Oil type R134a/R407C/R404A/R507A/R407A/R407F | BSE32(Standard) | R134a tc>70°C: BSE55 (Option) |
| Oil type R22 (R12/R502) | B5.2 (Option) |
| Oil type R1234yf | BSE32 (Standard) | R1234yf tc>70°C : BSE55 (Option) |
| Oil type R1234ze | BSE55 (Standard) | to>15°C: BSE85K (Option) | tc>70°C: BSE85K (Option) |
| Oil charge | 1.5 L |
